Magnum Press - I

• AC variable frequency drive for main motor.
• Outside controls for tablet weight and hardness.
• Lower punch seal is provided (for 45 sty. Not application)
• Auto lubrication system.
• Equipped with digital counter for production count.
• Chute & dust extractor nozzles are S.S.316.
• Adjustable upper punch penetration.
• Guard with interlock with transparent acrylic system for machine.
• Inching system for machine.
• Anti vibration mounting provided hence no foundation required.
• By-Layer Attachment (Optional).

Type	CM-I-27	CM-I-35	CM-I-45
Station / tooling	16 / D	20 / D	23 / B-D
No. Of Station	27	35	45
Max. pressure	10 kN	6.5 kN	6.5 kN
Max. Tablet Diameter	23 mm	13 mm	11 mm
Max.Depth of fill	20.5 mm	17.5 mm	17.5 mm
Upper punch penetration	3-8 mm	3-8 mm	3-8 mm
Max. turret RPM	48,600 to 1,62,000	63,000 to 2,10,000	81,000 to 2,70,000
Main electric motor	7.5 HP / 1440 RPM / 3 Ph	5 HP / 1440 RPM / 3 Ph	5 HP / 1440 RPM / 3 Ph

* Depending upon the characteristics and sha,res & size of tablets.
